AC Fans 80 x 80 x 25mm

diagram of panasonic dc fan
  • Dimensions: 80 x 80 x 25mm
  • Rated voltages: 100VAC, 115VAC
  • Frame: die-cast aluminum
  • Propeller: reinforced plastic
  • RoHS-compliant
specifications of pansonic dc fans

Diagram

airflow graph for pansonic dc fans

Materials used

  • Frame: Aluminum alloy
  • Fan blades: Fiberglass-reinforced plastic
  • Bearings: Ball bearings
  • Lead wires: UL3266 and AWG22

Specifications

  • Operating voltage:±10% of rated voltage
  • Ambient temperature:Storage: -20℃ to +70℃; operation: -10℃ to +60℃
  • Ambient humidity:Max. 85% (RH)
  • Temperature rise:Coil: max. 50℃; surface: max. 20℃
  • Breakdown voltage:1,500VAC for 1min
  • Insulation resistance:Min. 100MO (at 500VDC)
  • Vibration resistance:10 to 55Hz; amplitude 0.75mm; applied for 10min in 3 directions
  • Fan blockage:No coil burnout after 72-hour blockage at nominal voltage
  • Protection:Impedance protected
  • Lifetime:50,000 hours
